Nominal Size or Basic Product Diameter
|
Body or Shoulder Diameter, E
|
Width Across Flast,F
|
Width Across Corners,G
|
Head Height,H
|
Minimum Shoulder Length,S
|
Radius of Filler,R
|
||||||||
|
Max.
|
Min.
|
Basic
|
Max.
|
Min.
|
Max.
|
Min.
|
Basic
|
Max.
|
Min.
|
Max.
|
Min.
|
|||
|
No.10
|
0.1900
|
0.199
|
0.178
|
9/32
|
0.281
|
0.271
|
0.398
|
0.372
|
1/8
|
0.140
|
0.110
|
0.094
|
0.03
|
0.01
|
|
1/4
|
0.2500
|
0.260
|
0.237
|
3/8
|
0.375
|
0.362
|
0.530
|
0.498
|
11/64
|
0.188
|
0.156
|
0.094
|
0.03
|
0.01
|
|
5/16
|
0.3125
|
0.324
|
0.298
|
1/2
|
0.500
|
0.484
|
0.707
|
0.665
|
13/64
|
0.220
|
0.186
|
0.125
|
0.03
|
0.01
|
|
3/8
|
0.3750
|
0.388
|
0.360
|
9/16
|
0.562
|
0.544
|
0.795
|
0.747
|
1/4
|
0.268
|
0.232
|
0.125
|
0.03
|
0.01
|
|
7/16
|
0.4375
|
0.452
|
0.421
|
5/8
|
0.625
|
0.603
|
0.884
|
0.828
|
19/64
|
0.316
|
0.278
|
0.156
|
0.03
|
0.01
|
|
1/2
|
0.5000
|
0.515
|
0.482
|
3/4
|
0.750
|
0.725
|
1.061
|
0.995
|
21/64
|
0.348
|
0.308
|
0.156
|
0.03
|
0.01
|
|
5/8
|
0.6250
|
0.642
|
0.605
|
15/16
|
0.938
|
0.906
|
1.326
|
1.244
|
27/64
|
0.444
|
0.400
|
0.312
|
0.06
|
0.02
|
|
3/4
|
0.7500
|
0.768
|
0.729
|
1 1/8
|
1.125
|
1.088
|
1.591
|
1.494
|
1/2
|
0.524
|
0.476
|
0.375
|
0.06
|
0.02
|
|
7/8
|
0.8750
|
0.895
|
0.852
|
1 5/16
|
1.312
|
1.269
|
1.856
|
1.742
|
19/32
|
0.620
|
0.568
|
0.375
|
0.06
|
0.02
|
|
1
|
1.0000
|
1.022
|
0.976
|
1 1/2
|
1.500
|
1.450
|
2.121
|
1.991
|
21/32
|
0.684
|
0.628
|
0.625
|
0.09
|
0.03
|
|
1 1/8
|
1.1250
|
1.149
|
1.098
|
1 11/16
|
1.688
|
1.631
|
2.386
|
2.239
|
3/4
|
0.78
|
0.720
|
0.625
|
0.09
|
0.03
|
|
1 1/4
|
1.2500
|
1.277
|
1.223
|
1 7/8
|
1.875
|
1.812
|
2.652
|
2.489
|
27/32
|
0.876
|
0.812
|
0.625
|
0.09
|
0.03
|
