ASME B18.15 Forged Eyebolts Type 2



TYPE 2, STYLES A AND B SHOULDER PATTERN EYEBOLT
Nominal Size
A
B
C
D
E
F
G
H
J
K
L
R
Shank Dia
Shank Length
Eye ID
Nominal
Eye
OD
Eye Sect Dia
Overall Length
Min Length Full Thread
Thread
Size
UNC-2A
Eye To Shoulder
Shoulder Diam.
Shoulder Height
Radius Under Shoulder
Style A
Style B
Style A
Style B
1/4 0.25 0.25
0.28		 1.00
1.06		 1.00
1.06		 0.69
0.81		 1.19 0.19
0.25		 2.22
2.53		 0.75 0.75 1/4-20 0.69
0.81		 0.50
0.56		 0.12
0.19		 0.015
0.025
5/16 0.31 0.31
0.34		 1.12
1.19		 1.06
1.13		 0.81
0.94		 1.44 0.25
0.31		 2.66
2.97		 0.81 0.75 5/16-18 0.88
1.00		 0.56
0.62		 0.12
0.19		 0.015
0.025
3/8 0.38 0.38
0.41		 1.25
1.38		 1.12
1.25		 0.94
1.06		 1.69 0.31
0.38		 3.09
3.47		 0.88 0.75 3/8-16 1.06
1.19		 0.62
0.69		 0.12
0.19		 0.015
0.025
7/16 0.44 0.44
0.47		 1.38
1.50		 1.13
1.25		 1.00
1.12		 1.81 0.34
0.41		 3.41
3.78		 1 0.75 7/16-14 1.19
1.31		 0.75
0.81		 0.19
0.25		 0.015
0.025
1/2 0.5 0.50
0.53		 1.50
1.62		 1.13
1.25		 1.12
1.25		 2.12 0.44
0.50		 3.81
4.19		 1.12 0.75 1/2-13 1.31
1.44		 0.88
0.94		 0.19
0.25		 0.015
0.025
9/15 0.56 0.56
0.59		 1.62
1.75		 1.21
1.34		 1.19
1.31		 2.25 0.47
0.53		 4.19
4.56		 1.25 0.84 9/15-12 1.50
1.62		 0.94
1.00		 0.22
0.28		 0.020
0.045
5/8 0.62 0.62
0.66		 1.75
1.88		 1.31
1.44		 1.31
1.44		 2.56 0.56
0.62		 4.56
4.94		 1.38 0.94 5/8-11 1.59
1.72		 1.00
1.06		 0.25
0.31		 0.020
0.045
3/4 0.75 0.75
0.78		 2.00
2.12		 1.50
1.62		 1.44
1.56		 2.81 0.62
0.69		 5.06
5.50		 1.62 1.12 3/4-10 1.72
1.91		 1.12
1.25		 0.25
0.31		 0.020
0.045
7/8 0.88 0.88
0.91		 2.25
2.38		 1.75
1.88		 1.56
1.69		 3.19 0.75
0.81		 5.75
6.19		 1.81 1.31 7/8-9 2.03
2.22		 1.31
1.44		 0.31
0.38		 0.040
0.065
1 1 1.00
1.06		 2.50
2.62		 1.94
2.06		 1.69
1.81		 3.56 0.88
0.94		 6.44
6.88		 2.06 1.5 1 - 8 2.22
2.41		 1.50
1.62		 0.38
0.44		 0.060
0.095
1 1/8 1.12 1.12
1.19		 2.75
2.88		 2.23
2.26		 1.94
2.06		 4.06 1.00
1.06		 7.31
7.75		 2.31 1.69 1 1/8 -7 2.59
2.78		 1.69
1.81		 0.44
0.50		 0.060
0.095
1 1/4 1.25 1.25
1.34		 3.00
3.12		 2.38
2.5		 2.12
2.25		 4.44 1.09
1.16		 8.00
8.44		 2.5 1.88 1 1/4 -7 2.84
3.03		 1.88
2.00		 0.50
0.56		 0.060
0.095
1 1/2 1.5 1.50
1.59		 3.50
3.62		 2.75
2.87		 2.44
2.56		 5.19 1.31
1.38		 9.22
9.72		 3 2.25 1 1/2 -6 3.19
3.44		 2.12
2.52		 0.50
0.62		 0.060
0.095
1 3/4 1.75 1.75
1.84		 3.75
3.88		 3.18
3.31		 2.75
3.00		 6 1.50
1.62		 10.50
11.12		 3.19 2.62 1 3/4 -5 3.88
4.12		 2.50
2.62		 0.50
0.62		 0.060
0.095
2 2 2.00
2.09		 4.00
4.12		 4.00
4.12		 3.06
3.44		 6.88 1.75
1.88		 11.53
12.22		 3.38 3 2 - 4 1/2 4.25
4.50		 2.88
3.00		 0.62
0.75		 0.060
0.095

Tags: ASME B18.15 Forged Eyebolts Type 2

General Material:Stainless Steel,Nickel Alloy,Silicon Bronze,Aluminium Bronze,Brass,Naval Brass,Coppe,Copper-Nickel,Aluminum Alloy,Titanium,Alloy Steel,Such as C1008,C1018,C1022,C1035,C1045,40cr,SCM435,35crmoA,42crmoA,AISI4140SS304/A2-70,SS316/A4-80,SS310s,SS309,SS321,SS410,SS317,SS904L,17-4 PH/630,Duplex 2205,Duplex 31803,Nitronic 40,Nitronic 50,Nitronic 60,Nickel Alloy,Hastelloy C276,Inconel 600,Inconel 601,Inconel 625,Inconel 718,Inconel X750,Inconel 800H,Inconel 825,Monel 400,Monel 405,Monel K-500,MP35N,Nickel 200,Nickel 201,Waspaloy)C65500,C64200,C61400,C63000,C63200,C46200,H59,H62,H67,C46400,C11000,90/10 C70600,70/30 C71500,6061-T6,2024-T4,Ti-6Al-4V Grade 5,ASTM B348 Grade 2,ASTM B348 Grade 7,651/S63198
General Surface Finish:Blackoxide,Zinc,Dacromet 500/Dacromet 320,Non-electrolytically Deposited Zinc Flake,Hot-dip Galvanization,Phosphating,Passviation
