DIN 610 - Hexagon Fit Bolts With Short Threaded Dog Point




Thread size d
M8
M10
M12
(M14)
M16
(M18)
M20
-
-
-
-
-
-
-
-
(M18*1.5)
M20*1.5
-
-
-
-
-
-
-
-
(M18*2)
M20*2
b (auxiliary dimension)
l≤125mm
11.5
13.5
15.5
17
19
21.5
22.5
125mm<l≤200mm
13.5
15.5
17.5
19
21
23.5
24.5
200mm <l
18.5
20.5
22.5
24
26
28.5
29.5
ds
K6
9
11
13
15
17
19
21
dg
min.
7.9
9.9
11.5
13.5
15.5
17.5
19.1
max.
8.2
10.2
11.8
13.8
15.8
17.8
19.4
e
min.
14.38
17.77
18.9
19.85
20.88
22.78
23.91
26.17
29.56
32.95
k
Nominal dimension
5.3
6.4
7.5
8.8
10
11.5
12.5
min.
5.15
6.22
7.21
8.51
9.71
11.15
12.15
max.
5.45
6.58
7.79
9.09
10.29
11.85
12.85
k '
min.
3.6
4.3
5.1
6
6.8
7.8
8.5
r
min.
0.4
0.4
0.6
0.6
0.6
0.6
0.8
max.
0.55
0.55
0.75
0.75
0.75
0.75
0.95
s
max.=  Nominal dimension
13
16
17
18
19
21
22
24
27
30
min.
12.73
15.73
16.73
17.57
18.48
20.16
21.16
23.16
26.16
29.16
Thread size d
M22
M24
M27
M30
(M33)
M36
(M39)
(M22*1.5)
M24*2
(M27*2)
M30*2
(M33*2)
M36*3
(M39*3)
(M22*2)
M24*1.5
-
-
-
-
-
-
-
b (auxiliary dimension)
l≤125mm
24.5
26.5
-
-
-
-
-
-
-
125mm<l≤200mm
26.5
28.5
31.5
34
36
40
42
200mm <l
31.5
33.5
36.5
39
41
45
47
ds
K6
23
25
28
32
34
38
40
dg
min.
21.1
23.1
25.7
29.7
31.7
35.7
37.7
max.
21.4
23.4
25
30
32
36
38
e
min.
35.03|37.29
39.55
45.2
50.85
55.37
60.79
66.44
k
Nominal dimension
14
15
17
19
21
22
25
min.
13.65
14.65
16.65
18.58
20.58
21.58
24.58
max.
14.35
15.35
17.35
19.42
21.42
22.42
25.42
k '
min.
9.6
10.2
11.7
13
14.4
15.1
17.2
r
min.
0.8
0.8
1
1
1
1
1
max.
0.95
0.95
1.15
1.15
1.15
1.15
1.15

s
max.=  Nominal dimension
32|34
36
41
46
50
55
60
min.
31|33
35
40
45
49
53.8
58.8

Tags: DIN 610 Hexagon Fit Bolts With Short Threaded Dog Point

General Material:Stainless Steel,Nickel Alloy,Silicon Bronze,Aluminium Bronze,Brass,Naval Brass,Coppe,Copper-Nickel,Aluminum Alloy,Titanium,Alloy Steel,Such as C1008,C1018,C1022,C1035,C1045,40cr,SCM435,35crmoA,42crmoA,AISI4140SS304/A2-70,SS316/A4-80,SS310s,SS309,SS321,SS410,SS317,SS904L,17-4 PH/630,Duplex 2205,Duplex 31803,Nitronic 40,Nitronic 50,Nitronic 60,Nickel Alloy,Hastelloy C276,Inconel 600,Inconel 601,Inconel 625,Inconel 718,Inconel X750,Inconel 800H,Inconel 825,Monel 400,Monel 405,Monel K-500,MP35N,Nickel 200,Nickel 201,Waspaloy)C65500,C64200,C61400,C63000,C63200,C46200,H59,H62,H67,C46400,C11000,90/10 C70600,70/30 C71500,6061-T6,2024-T4,Ti-6Al-4V Grade 5,ASTM B348 Grade 2,ASTM B348 Grade 7,651/S63198
General Surface Finish:Blackoxide,Zinc,Dacromet 500/Dacromet 320,Non-electrolytically Deposited Zinc Flake,Hot-dip Galvanization,Phosphating,Passviation
