DIN 603 - Mushroom Head Square Neck Bolts





Screw Thread d
M5
m6
M8
M10
M12
M16
M20
P
0.8
1
1.25
1.5
1.75
2
2.5
b
l≤125mm
16
18
22
26
30
38
46
125mm<l≤200mm
22
24
28
32
36
44
52
200mm <l
/
/
41
45
49
57
65
dk

max.
13.55
16.55
20.65
24.65
30.65
38.8
46.8
min.
12.45
15.45
19.35
23.35
29.35
37.2
45.2
ds

max.
5
6
8
10
12
16
20
min.
4.52
5.52
7.42
9.42
11.3
15.3
19.16
f

max.
4.1
4.6
5.6
6.6
8.75
12.9
15.9
min.
2.9
3.4
4.4
5.4
7.25
11.1
14.1
k

max.
3.3
3.88
4.88
5.38
6.95
8.95
11.05
min.
2.7
3.12
4.12
4.62
6.05
8.05
9.5
r1

max.
10.7
12.6
16
19.2
24.1
29.3
33.9
r2
max.
0.5
0.5
0.5
0.5
1
1
1
r3
max.
0.75
0.9
1.2
1.5
1.8
2.4
3
v

max.
5.48
6.48
8.58
10.58
12.7
16.7
20.84
min.
4.52
5.52
7.42
9.42
11.3
15.3
19.16

Tags: DIN 603 Mushroom Head Square Neck Bolts

General Material:Stainless Steel,Nickel Alloy,Silicon Bronze,Aluminium Bronze,Brass,Naval Brass,Coppe,Copper-Nickel,Aluminum Alloy,Titanium,Alloy Steel,Such as C1008,C1018,C1022,C1035,C1045,40cr,SCM435,35crmoA,42crmoA,AISI4140SS304/A2-70,SS316/A4-80,SS310s,SS309,SS321,SS410,SS317,SS904L,17-4 PH/630,Duplex 2205,Duplex 31803,Nitronic 40,Nitronic 50,Nitronic 60,Nickel Alloy,Hastelloy C276,Inconel 600,Inconel 601,Inconel 625,Inconel 718,Inconel X750,Inconel 800H,Inconel 825,Monel 400,Monel 405,Monel K-500,MP35N,Nickel 200,Nickel 201,Waspaloy)C65500,C64200,C61400,C63000,C63200,C46200,H59,H62,H67,C46400,C11000,90/10 C70600,70/30 C71500,6061-T6,2024-T4,Ti-6Al-4V Grade 5,ASTM B348 Grade 2,ASTM B348 Grade 7,651/S63198
General Surface Finish:Blackoxide,Zinc,Dacromet 500/Dacromet 320,Non-electrolytically Deposited Zinc Flake,Hot-dip Galvanization,Phosphating,Passviation
