Thread Size
|
M5
|
M6
|
M8
|
M10
|
M12
|
M14
|
M16
|
||
P
|
0.8
|
1
|
1.25
|
1.5
|
1.75
|
2
|
2
|
||
b
|
l≤125mm
|
16
|
18
|
22
|
26
|
30
|
34
|
38
|
|
125mm<l≤200mm
|
22
|
24
|
28
|
32
|
36
|
40
|
44
|
||
200mm <l
|
35
|
37
|
41
|
45
|
49
|
53
|
57
|
||
c
|
max.
|
0.5
|
0.5
|
0.6
|
0.6
|
0.6
|
0.6
|
0.8
|
|
da
|
max.
|
6
|
7.2
|
10.2
|
12.2
|
14.7
|
16.7
|
18.7
|
|
dw
|
min.
|
6.7
|
8.7
|
11.4
|
15.4
|
17.2
|
19.2
|
22
|
|
ds
|
Nominal Size
|
5
|
6
|
8
|
10
|
12
|
14
|
16
|
|
min.
|
4.52
|
5.52
|
7.42
|
9.42
|
11.3
|
13.3
|
15.3
|
||
max.
|
5.48
|
6.48
|
8.58
|
10.58
|
12.7
|
14.7
|
16.7
|
||
e min.
|
8.63
|
10.89
|
14.2
|
18.72
|
20.88
|
22.78
|
26.17
|
||
k
|
Nominal Size
|
3.5
|
4
|
5.3
|
6.4
|
7.5
|
8.8
|
10
|
|
min.
|
3.12
|
3.62
|
4.92
|
5.95
|
7.05
|
8.35
|
9.25
|
||
max.
|
3.88
|
4.38
|
5.68
|
6.85
|
7.95
|
9.25
|
10.75
|
||
k'
|
min.
|
2.2
|
2.5
|
3.45
|
4.2
|
4.95
|
5.85
|
6.5
|
|
r
|
min.
|
0.2
|
0.25
|
0.4
|
0.4
|
0.6
|
0.6
|
0.6
|
|
s
|
max. = Nominal Size
|
8
|
10
|
13
|
17
|
19
|
21
|
24
|
|
min.
|
7.64
|
9.64
|
12.57
|
16.57
|
18.48
|
20.16
|
23.16
|
Tags: DIN 601 Hexagon Head Bolts With Half Thread
General Material:Stainless Steel,Nickel Alloy,Silicon Bronze,Aluminium Bronze,Brass,Naval Brass,Coppe,Copper-Nickel,Aluminum Alloy,Titanium,Alloy Steel,Such as C1008,C1018,C1022,C1035,C1045,40cr,SCM435,35crmoA,42crmoA,AISI4140SS304/A2-70,SS316/A4-80,SS310s,SS309,SS321,SS410,SS317,SS904L,17-4 PH/630,Duplex 2205,Duplex 31803,Nitronic 40,Nitronic 50,Nitronic 60,Nickel Alloy,Hastelloy C276,Inconel 600,Inconel 601,Inconel 625,Inconel 718,Inconel X750,Inconel 800H,Inconel 825,Monel 400,Monel 405,Monel K-500,MP35N,Nickel 200,Nickel 201,Waspaloy)C65500,C64200,C61400,C63000,C63200,C46200,H59,H62,H67,C46400,C11000,90/10 C70600,70/30 C71500,6061-T6,2024-T4,Ti-6Al-4V Grade 5,ASTM B348 Grade 2,ASTM B348 Grade 7,651/S63198
General Surface Finish:Blackoxide,Zinc,Dacromet 500/Dacromet 320,Non-electrolytically Deposited Zinc Flake,Hot-dip Galvanization,Phosphating,Passviation
