DIN 546 - Slotted Round Nuts




Thread size d
M1
M1.2
M1.4
M1.6
M2
M2.5
M3
M3.5
M4
p
0.25
0.25
0.3
0.35
0.4
0.45
0.5
0.6
0.7
da
min
1
1.2
1.4
1.6
2
2.5
3
3.45
4
max
1.15
1.4
1.6
1.84
2.3
2.9
3.5
4
4.6
dk
max
2.5
3
3
3.5
4.5
5.5
6
7
8
min
2.25
2.75
2.75
3.2
4.2
5.2
5.7
6.64
7.64
m
max
1
1.2
1.4
1.6
2
2.2
2.5
3
3.5
min
0.75
0.95
1.15
1.35
1.75
1.95
2.25
2.75
3.2
n
nominal size
0.3
0.4
0.4
0.5
1
1.2
1.2
1.4
1.4
min
0.36
0.46
0.46
0.56
1.06
1.26
1.26
1.46
1.46
max
0.5
0.6
0.6
0.7
1.2
1.51
1.51
1.71
1.71
t
min
0.3
0.4
0.5
0.6
0.8
0.9
1
1
1.2
max
0.5
0.6
0.7
0.8
1
1.1
1.2
1.4
1.6
Thread size d
M5
M6
M8
M10
M12
M14
M16
M18
M20
p
0.8
1
1.25
1.5
1.75
2
2
2.5
2.5
da
min
5
6
8
10
12
14
16
18
20
max
5.75
6.75
8.75
10.8
13
15.1
17.3
19.5
21.8
dk
max
9
11
14
18
21
24
26
29
32
min
8.64
10.57
13.57
17.57
20.48
23.48
25.48
28.48
21.38
m
max
4.2
5
6.5
8
10
11
12
13
14
min
3.9
4.7
6.14
7.64
9.64
10.57
11.57
12.57
13.57
n
nominal size
2
2.5
3
3.5
4
4
4
4
5
min
2.06
2.56
3.06
3.57
4.07
4.07
4.07
4.07
5.07
max
2.31
2.81
3.31
3.87
4.37
4.37
4.37
4.37
5.37
t
min
1.5
2
2.5
3.2
3.8
3.8
3.8
4.8
4.8
max
1.9
2.4
3
3.7
4.3
4.3
4.3
5.5
5.5

Tags: DIN 546, Slotted Round Nuts,

General Material:Stainless Steel,Nickel Alloy,Silicon Bronze,Aluminium Bronze,Brass,Naval Brass,Coppe,Copper-Nickel,Aluminum Alloy,Titanium,Alloy Steel,Such as C1008,C1018,C1022,C1035,C1045,40cr,SCM435,35crmoA,42crmoA,AISI4140SS304/A2-70,SS316/A4-80,SS310s,SS309,SS321,SS410,SS317,SS904L,17-4 PH/630,Duplex 2205,Duplex 31803,Nitronic 40,Nitronic 50,Nitronic 60,Nickel Alloy,Hastelloy C276,Inconel 600,Inconel 601,Inconel 625,Inconel 718,Inconel X750,Inconel 800H,Inconel 825,Monel 400,Monel 405,Monel K-500,MP35N,Nickel 200,Nickel 201,Waspaloy)C65500,C64200,C61400,C63000,C63200,C46200,H59,H62,H67,C46400,C11000,90/10 C70600,70/30 C71500,6061-T6,2024-T4,Ti-6Al-4V Grade 5,ASTM B348 Grade 2,ASTM B348 Grade 7,651/S63198
General Surface Finish:Blackoxide,Zinc,Dacromet 500/Dacromet 320,Non-electrolytically Deposited Zinc Flake,Hot-dip Galvanization,Phosphating,Passviation
