DIN 1480 -TurnbucklesForged open form



Thread
M6
M8
M10
M12
M16
M20
M24
M30
M36
M42
M48
M56
l1
110
110
125
125
170
200
255
255
295
330
355
355
e
19
23
30
34
42
52
60
74
86
104
135
135
f
9
11
14
16
20
24
28
34
40
50
65
65
h
6
8
9
11
14
17
20
23
28
32
40
40
d2
12
15
18
21
27
34
39
45
55
63
80
80
m1
12
15
18
21
27
34
39
45
55
63
78
78
m2
6
8
9
11
14
17
20
23
28
32
39
39

Tags: DIN 1480 Turnbuckles open form

General Material:Stainless Steel,Nickel Alloy,Silicon Bronze,Aluminium Bronze,Brass,Naval Brass,Coppe,Copper-Nickel,Aluminum Alloy,Titanium,Alloy Steel,Such as C1008,C1018,C1022,C1035,C1045,40cr,SCM435,35crmoA,42crmoA,AISI4140SS304/A2-70,SS316/A4-80,SS310s,SS309,SS321,SS410,SS317,SS904L,17-4 PH/630,Duplex 2205,Duplex 31803,Nitronic 40,Nitronic 50,Nitronic 60,Nickel Alloy,Hastelloy C276,Inconel 600,Inconel 601,Inconel 625,Inconel 718,Inconel X750,Inconel 800H,Inconel 825,Monel 400,Monel 405,Monel K-500,MP35N,Nickel 200,Nickel 201,Waspaloy)C65500,C64200,C61400,C63000,C63200,C46200,H59,H62,H67,C46400,C11000,90/10 C70600,70/30 C71500,6061-T6,2024-T4,Ti-6Al-4V Grade 5,ASTM B348 Grade 2,ASTM B348 Grade 7,651/S63198
General Surface Finish:Blackoxide,Zinc,Dacromet 500/Dacromet 320,Non-electrolytically Deposited Zinc Flake,Hot-dip Galvanization,Phosphating,Passviation
