DIN 7346 - Spring-type straight pins Roll pins Light-weight type



Nominal diameter
2
2.5
3
3.5
4
4.5
5
6
7
8
10
11
12
13
a
0.2
0.25
0.25
0.3
0.5
0.5
0.5
0.7
0.7
1.5
2
2
2
2
Before insertation
d1 min.
2.3
2.8
3.3
3.8
4.4
4.8
5.4
6.4
7.5
8.5
10.5
11.5
12.5
13.5
d1 max.
2.4
2.9
3.5
4
4.6
5
5.6
6.7
7.8
8.8
10.8
11.8
12.8
13.8
d2 ≈
1.9
2.3
2.7
3.1
3.4
3.8
4.4
4.9
6
7
0.5
9.5
10.5
11
s
0.2
0.25
0.3
0.35
0.5
0.5
0.5
0.75
0.75
0.75
1
1
1
1.25
Shearing force in kN
Single shear
0.75
1.2
1.75
2.3
4
4.4
5.2
9
10.5
12
20
22
24
33
Double shear
1.5
2.4
3.5
4.6
8
8.8
10.4
18
21
24
40
44
48
66
l
per.dev.
Weight (7.85 kg/dm3) kg/1000 pieces
4
+0.5
0
0.034
0.054
0.078
0.106
0.168
0.193
















5
0.043
0.067
0.097
0.132
0.21
0.241
0.271














6
0.051
0.08
0.116
0.159
0.252
0.289
0.325














8
0.068
0.107
0.155
0.212
0.336
0.385
0.433














10
0.085
0.134
0.193
0.264
0.42
0.481
0.541
0.93
1.11
1.3
2.14
2.32
2.63
3.51
12
+1
0
0.102
0.161
0.232
0.317
0.504
0.578
0.65
1.12
1.33
1.55
2.57
2.78
3.16
4.22
14
0.119
0.187
0.271
0.37
0.588
0.674
0.758
1.3
1.55
1.81
3
3.24
3.68
4.92
16
0.136
0.214
0.309
0.423
0.672
0.77
0.866
1.49
1.77
2.07
3.43
3.71
4.21
5.62
18
0.153
0.241
0.348
0.476
0.756
0.866
0.974
1.67
1.99
2.33
3.86
4.16
4.74
6.32
20
0.17
0.267
0.386
0.528
0.84
0.962
1.08
1.86
2.21
2.59
4.29
4.63
5.26
7.03
22
0.187
0.294
0.425
0.581
0.924
1.06
1.19
2.05
2.44
2.85
4.72
5.1
5.79
7.73
24
0.204
0.321
0.464
0.634
1.01
1.16
1.3
2.23
2.66
3.11
5.14
5.56
6.31
8.43
26
0.221
0.347
0.502
0.687
1.09
1.25
1.41
2.42
2.88
3.77
5.57
6.03
6.84
9.13
28
0.238
0.374
0.541
0.74
1.18
1.35
1.52
2.6
3.1
3.63
6
6.48
7.36
9.84
30
0.255
0.4
0.579
0.792
1.26
1.44
1.62
2.79
3.32
3.88
6.43
6.95
7.89
10.5
32




0.618
0.845
1.34
1.54
1.73
2.98
3.54
4.14
6.86
7.4
8.42
11.2
36




0.695
0.951
1.51
1.73
1.95
3.49
3.99
4.66
7.72
8.32
9.47
12.6
40




0.772
1.06
1.68
1.92
2.16
3.72
4.43
5.18
8.57
9.3
40.5
14.1
45








1.89
2.16
2.44
4.18
4.98
5.83
9.64
10.4
11.8
15.8
50








2.1
2.4
2.7
4.65
5.54
6.48
10.7
11.6
13.2
17.6
55
+1.5
0












2.98
5.12
6.09
7.12
11.8
12.7
14.5
19.3
60












3.25
5.58
6.64
7.77
12.9
13.9
15.8
21.1
65












3.52
6.04
7.2
8.42
13.9
15
17.1
22.8
70












3.79
6.51
7.75
9.06
15
16.2
18.4
24.6
75












4.06
6.98
8.3
9.71
16.1
17.4
19.7
26.3
80












4.33
7.44
8.86
10.4
17.1
18.5
21
28.1
85














7.9
9.41
11
18.2
19.7
22.4
29.9
90














8.37
9.96
11.7
19.3
20.6
23.7
31.6
95














8.84
10.6
12.3
20.4
22
25
33.4
100














9.3
11.1
13
21.4
23.2
26.3
35.1
120


















15.5
25.7
27.8
31.6
42.2
140




















30
32.4
36.8
49.2
160




















34.3
37.1
42.1
56.2
180
























47.4
63.2

Nominal diameter
14
16
18
20
21
23
25
28
30
35
40
45
50


a
2
2
2
2
2
3
3
3
3
3
4
4
4


Before insertation
d1 min.
14.5
16.5
18.5
20.5
21.5
23.5
25.5
28.5
30.5
35.5
40.5
45.5
50.5


d1 max.
14.8
16.8
18.9
20.9
21.9
23.9
25.9
28.9
30.9
35.9
40.9
45.9
50.9


d2 ≈
11.5
13.5
15
16.5
17.5
19.5
21.5
23.5
25.5
28.5
32.5
37.5
40.5


s
1.5
1.5
1.75
2
2
2
2
2.5
2.5
3.5
4
4
5


Shearing force in kN
Single shear
42
49
63
79
84
92
101
140
151
245
317
360
500


Double shear
84
98
126
158
168
184
202
280
302
490
634
720
1000


l
per.dev.
Weight (7.85 kg/dm3) kg/1000 pieces


10
+0.5
0
4.48
5.2
6.81
8.64






















12
+1
0
5.37
6.25
8.18
10.4




















14
6.27
7.29
9.54
12.1
12.8
14.1
15.4
21.6
23.3










16
7.16
8.33
10.9
13.8
14.6
16.1
17.6
24.6
26.6










18
8.06
9.37
12.3
15.5
16.4
18.1
19.8
27.7
29.9










20
8.95
10.4
13.6
17.3
18.2
20.1
22
30.8
33.2
53.4
69.9
79.1
109


22
9.85
11.5
15
19
20.1
22.1
24.2
33.9
36.6
58.8
76.9
87
120


24
10.7
12.5
16.4
20.7
21.9
24.1
26.4
37
39.9
64.1
83.9
94.9
131


26
11.6
13.5
17.7
22.5
23.7
26.1
28.6
40.1
43.2
69.4
90.9
103
142


28
12.5
14.6
19.1
24.2
25.5
28.1
30.8
43.1
46.5
74.8
97.9
111
153


30
13.4
15.6
20.4
25.9
27.4
30.1
33
46.2
49.9
80.1
105
119
164


32
14.3
16.7
21.8
27.6
29.2
32.2
35.2
49.3
53.3
85.5
112
127
174


36
16.1
18.7
24.5
31.1
32.8
36.2
39.6
55.5
59.8
96.1
126
142
196


40
17.9
20.8
27.3
34.5
36.5
40.2
43.9
61.6
66.5
107
140
158
218


45
20.1
23.4
30.7
38.8
41
45.2
49.5
69.3
74.8
120
157
178
245


50
22.4
26
34.1
43.2
45
50.2
55
77
83.1
134
175
198
273


55
+1.5
0
24.6
28.6
37.5
47.5
50.2
55.3
60.4
84.8
91.4
147
192
217
300


60
26.8
31.2
40.9
51.8
54.7
60.3
65.9
92.4
99.7
160
210
237
327


65
29.1
33.8
44.3
56.1
59.3
65.3
71.4
100
108
174
227
257
354


70
31.3
36.4
47.7
60.4
63.8
70.3
76.9
108
116
187
245
277
382


75
33.6
39
511
64.8
68.4
75.4
82.4
115
125
200
262
296
409


80
35.8
41.6
54.5
69.1
73
80.4
87.9
123
133
214
280
316
436


85
38
44.2
57.9
73.4
77.5
85.4
93.4
131
141
227
297
336
463


90
40.3
46.8
61.3
77.7
82.1
90.4
98.9
139
150
240
315
356
491


95
42.5
49.4
64.7
82
86
95.5
104
146
158
254
332
376
518


100
44.8
52
68.1
86.3
91.2
100
110
154
166
267
349
395
545


120
53.7
62.5
81.8
104
109
121
132
185
199
320
419
474
654


140
62.6
72.9
95.4
121
128
141
154
216
233
374
489
553
763


160
71.6
83.3
109
138
146
161
176
246
266
427
559
633
872


180
80.6
93.7
123
155
164
181
198
277
299
481
629
712
981


200
89.6
104
136
173
182
201
220
308
332
534
699
791
1090
