DIN-Fasteners/DIN 15237 - seating screws and cupped washers for the attachment of components to belts



d1
M6
M8
M10
M12
d3
20
28
35
42
a
14
20
25
30
cmax
1
1
1
1,2
g
3,5
5
6
7
k
2,5
3,5
4,5
5,2
r
20
28
35
42
Washer
　

M6
M8
M10
M12
d2
7
9,5
11,5
14
d4
25
32
40
50
r2
22
28
36
46
f
1,5
1,5
2
2
h
4,5
5,5
7
8
