DIN 470 - Sealing washers




d  js11
h
r
s   +/-0.15
3
1.20
3
0,8
4
1.34
4
0,8
5
1.35
6
0,8
6
1.67
7
1
8
1.94
9
1
10
2,67
12
1,6
12
2,77
16
1,6
14
2,94
19
1,6
16
3,11
22
1,6
18
3,28
25
1,6
20
3,45
28
1,6
22
4,09
30
2
25
4,38
34
2
28
4,53
40
2
(30
4,77
42
2
32
4,95
45
2
(34
5,11
48
2
36
5,36
50
2
(38
5.60
52
2
40
5.70
56
2
(42
5.80
60
2
45
6,15
63
2
(48
6,38
68
2
50
6,62
70
2
(52
6,66
75
2
56
7,06
80
2
(60
7,47
85
2
63
7.70
90
2
80
10,41
112
3
100
12,23
140
3
125
14,2
180
3

Tags: DIN 470, Sealing Washers,

General Material:Stainless Steel,Nickel Alloy,Silicon Bronze,Aluminium Bronze,Brass,Naval Brass,Coppe,Copper-Nickel,Aluminum Alloy,Titanium,Alloy Steel,Such as C1008,C1018,C1022,C1035,C1045,40cr,SCM435,35crmoA,42crmoA,AISI4140SS304/A2-70,SS316/A4-80,SS310s,SS309,SS321,SS410,SS317,SS904L,17-4 PH/630,Duplex 2205,Duplex 31803,Nitronic 40,Nitronic 50,Nitronic 60,Nickel Alloy,Hastelloy C276,Inconel 600,Inconel 601,Inconel 625,Inconel 718,Inconel X750,Inconel 800H,Inconel 825,Monel 400,Monel 405,Monel K-500,MP35N,Nickel 200,Nickel 201,Waspaloy)C65500,C64200,C61400,C63000,C63200,C46200,H59,H62,H67,C46400,C11000,90/10 C70600,70/30 C71500,6061-T6,2024-T4,Ti-6Al-4V Grade 5,ASTM B348 Grade 2,ASTM B348 Grade 7,651/S63198
General Surface Finish:Blackoxide,Zinc,Dacromet 500/Dacromet 320,Non-electrolytically Deposited Zinc Flake,Hot-dip Galvanization,Phosphating,Passviation
